WPRKAB drop-out plate

Drop-out plate for wide-span cable trays.

Continously hot galvanized (Sendzimir process) (DIN EN 10346)

	height	width	length	radius	t material thickness	weight
WPRKAB 20S	129 mm	190 mm	110 mm	100 mm	1,5 mm	0,47 kg
WPRKAB 30S	129 mm	290 mm	110 mm	100 mm	1,5 mm	0,71 kg
WPRKAB 40S	129 mm	390 mm	110 mm	100 mm	1,5 mm	0,95 kg
WPRKAB 50S	129 mm	490 mm	110 mm	100 mm	1,5 mm	1,19 kg
WPRKAB 60S	129 mm	590 mm	110 mm	100 mm	1,5 mm	1,43 kg

Hot-dip galvanized, according to BS 729 (DIN EN ISO 1461)

	height	width	length	radius	t material thickness	weight
WPRKAB 20F	129 mm	190 mm	110 mm	100 mm	1,5 mm	0,37 kg
WPRKAB 30F	129 mm	290 mm	110 mm	100 mm	1,5 mm	0,76 kg
WPRKAB 40F	129 mm	390 mm	110 mm	100 mm	1,5 mm	1,01 kg
WPRKAB 50F	129 mm	490 mm	110 mm	100 mm	1,5 mm	1,28 kg
WPRKAB 60F	129 mm	590 mm	110 mm	100 mm	1,5 mm	1,53 kg

Stainless steel, according to ASTM 304 / BS 304 S 3

	height	width	length	radius	t material thickness	weight
WPRKAB 20E	129 mm	190 mm	110 mm	100 mm	1,5 mm	0,48 kg
WPRKAB 30E	129 mm	290 mm	110 mm	100 mm	1,5 mm	0,72 kg
WPRKAB 40E	129 mm	390 mm	110 mm	100 mm	1,5 mm	0,97 kg
WPRKAB 50E	129 mm	490 mm	110 mm	100 mm	1,5 mm	1,22 kg
WPRKAB 60E	129 mm	590 mm	110 mm	100 mm	1,5 mm	1,46 kg

Details / Applications
