Ceiling bracket support, U-profile 40x30x2 mm, continuously three-way perforated, with welded head plate (material thickness t), certified according to DIN EN 61537.
Assembly Instruction
Hot-dip galvanized, according to BS 729 (DIN EN ISO 1461)
| length | t material thickness | weight | ||
|---|---|---|---|---|
| KDU 40-02F | 200 mm | 4,00 mm | 0,38 kg | |
| KDU 40-03F | 300 mm | 4,00 mm | 0,50 kg | |
| KDU 40-04F | 400 mm | 4,00 mm | 0,62 kg | |
| KDU 40-05F | 500 mm | 4,00 mm | 0,73 kg | |
| KDU 40-06F | 600 mm | 4,00 mm | 0,86 kg | |
| KDU 40-07F | 700 mm | 4,00 mm | 0,98 kg | |
| KDU 40-08F | 800 mm | 4,00 mm | 1,10 kg | |
| KDU 40-09F | 900 mm | 4,00 mm | 1,22 kg | |
| KDU 40-10F | 1000 mm | 4,00 mm | 1,34 kg | |
| KDU 40-11F | 1100 mm | 4,00 mm | 1,46 kg | |
| KDU 40-12F | 1200 mm | 4,00 mm | 1,58 kg | |
| KDU 40-13F | 1300 mm | 4,00 mm | 1,70 kg | |
| KDU 40-14F | 1400 mm | 4,00 mm | 1,82 kg | |
| KDU 40-15F | 1500 mm | 4,00 mm | 1,94 kg |
